AIRCRAFT
Weight (With Propellers, No Accessories):
DJI Mavic 3T: 2.03 lbs (920 g)
Max Takeoff Weight:
DJI Mavic 3T: 2.31 lbs (1,050 g)
Dimensions:
Folded (without propellers): 221×96.3×90.3 mm (L×W×H)
Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)
Diagonal Distance: 380.1 mm
Max Ascent Speed:
13.4 mph (6 m/s) (Normal Mode)
17.9 mph (8 m/s) (Sport Mode)
Max Descent Speed:
13.4 mph (6 m/s) (Normal Mode)
13.4 mph (6 m/s) (Sport Mode)
Max Flight Speed (at sea level, no wind):
Normal Mode: 33.5 mph (15 m/s) (Normal Mode)
Sport Mode:
Forward: 47 mph (21 m/s)
Side: 44.7 mph (20 m/s)
Backward: 42.5 mph (19 m/s)
Max Wind Speed Resistance: 26.8 mph (12 m/s)
Max Take-off Altitude Above Sea Level:
19,685 ft (6000 m) (without payload)
Max Flight Time (no wind): 45 minutes
Max Hover Time (no wind): 38 minutes
Max Flight Distance: 19.8 mi (32 km)
Max Tilt Angle:
30° (Normal Mode)
35° (Sport Mode)
Max Angular Velocity: 200°/s
GNSS:
GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)
Hovering Accuracy:
Vertical: ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
Horizontal: ±0.3 m (with Vision System); ±0.5 m (with High-Precision Positioning System); ±0.1 m (with RTK)
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Internal Storage: N/A
Motor Model: 2008
Propeller Model: 9453F Propellers for Enterprise
Beacon: Built into the aircraft
WIDE ANGLE CAMERA
Sensor:
1/2-inch CMOS, Effective pixels: 48 MP
Lens:
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8
Focus: 1 m to 8
ISO Range:
100-25600
Shutter Speed:
Electronic Shutter: 8-1/8000 s
Max Image Size:
8000×6000
Still Photography Modes:
Single: 12 MP/48 MP
Timed: 12 MP/48 MP
JPEG: 2/3/5/7/10/15/20/30/60 s*
Panorama: 12 MP (raw image); 100 MP (stitched image)
Smart Low-light Shooting: 12 MP
* Shooting 48MP photo does not support 2s interval
Video Resolution:
H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Bitrate:
4K: 85 Mbps
FHD: 30 Mbps
Supported File Formats: exFAT
Photo Format: JPEG
Video Format: MP4 (MPEG-4 AVC/H.264)
TELE CAMERA
Sensor: 1/2-inch CMOS, Effective pixels: 12 MP
Lens:
FOV: 15°
Format Equivalent: 162 mm
Aperture: f/4.4
Focus: 3 m to 8
ISO Range: 100-25600
Shutter Speed:
Electronic Shutter: 8-1/8000 s
Max Image Size: 4000×3000
Photo Format: JPEG
Video Format: MP4 (MPEG-4 AVC/H.264)
Still Photography Modes:
Single: 12 MP
Timed: 12 MP
JPEG: 2/3/5/7/10/15/20/30/60 s
Smart Low-light Shooting: 12 MP
Video Resolution:
H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Bitrate:
4K: 85 Mbps
FHD: 30 Mbps
Digital Zoom: 8x (56x hybrid zoom)
THERMAL CAMERA
Thermal Imager: Uncooled VOx Microbolometer
Pixel Pitch: 12 µm
Frame Rate: 30 Hz
Lens:
DFOV: 61°
Format Equivalent: 40 mm
Aperture: f/1.0
Focus: 5 m to 8
Sensitivity: =50 [email protected]
Temperature Measurement Method:
Spot Meter, Area Measurement
Temperature Measurement Range:
-20° to 150° C (-4° to 302° F, High Gain Mode)
0° to 500° C (32° to 932° F, Low Gain Mode)
Palette:
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2
Photo Format:
JPEG (8-bit)
R-JPEG (16-bit)
Video Resolution: 640×512@30fps
Bitrate: 6 Mbps
Video Format:
MP4 (MPEG-4 AVC/H.264)
Still Photography Modes:
Single: 640×512
Timed: 640×512
JPEG: 2/3/5/7/10/15/20/30/60 s
Digital Zoom: 28x
Infrared Wavelength: 8-14 µm
Infrared Temperature Measurement Accuracy:
±2° C or ±2% (using the larger value)
GIMBAL
Stabilization: 3-axis (tilt, roll, pan)
Mechanical Range:
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -27° to 27°
Controllable Range:
Tilt: -90° to 35°
Pan: Not controllable
Max Control Speed (tilt): 100°/s
Angular Vibration Range: ±0.007°
SENSING SYSTEM
Type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.
Forward:
Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed =15 m/s
FOV: Horizontal 90°, Vertical 103°
Backward:
Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed =12 m/s
FOV: Horizontal 90°, Vertical 103°
Lateral:
Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed =15 m/s
FOV: Horizontal 90°, Vertical 85°
Upward:
Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed =6 m/s
FOV: Front and Back 100°, Left and Right 90°
Downward:
Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed =6 m/s
FOV: Front and Back 130°, Left and Right 160°
Operating Environment:
Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15)
Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)
VIDEO TRANSMISSION
Video Transmission System: DJI O3 Enterprise Transmission
Live View Quality: Remote Controller: 1080p/30fps
Operating Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Max Transmission Distance (Unobstructed, Free of Interference):
FCC: 9.32 mi (15 km)
CE: 4.97 mi (8 km)
SRRC: 4.97 mi (8 km)
MIC: 4.97 mi (8 km)
Max Transmission Distance (Obstructed):
Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
Max Download Speed:
15 MB/s (with DJI RC Pro Enterprise)
Latency (depending on environmental conditions and mobile device): Approx. 200 ms
Antenna: 4 Antennas, 2T4R
Transmission Power (EIRP):
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
