AIRCRAFT
Takeoff Weight:
Mavic 3 Pro: 33.8 oz (958 g)
Dimensions:
Folded (LxWxH without propellers): 9 x 3.85 x 3.75 in (231.1×98×95.4 mm)
Unfolded (LxWxH without propellers): 13.7 x 11.4 x 4.24 in (347.5×290.8×107.7 mm)
Max Ascent Speed:
17.9 mph (8 m/s)
Max Descent Speed:
13.42 mph (6 m/s)
Max Horizontal Speed (at sea level, no wind):
47 mph (21 m/s)
Max Takeoff Altitude:
19,685 ft (6000 m)
Max Flight Time: 43 minutes
Measured in a controlled test environment. Specific test conditions are as follows: flying at a constant speed of 32.4 kph in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.
Max Hovering Time: 37 minutes
Measured in a controlled test environment. Specific test conditions are as follows: hovering in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.
Max Flight Distance:
17.4 mi (28 km)
Max Wind Speed Resistance:
26.8 mph (12 m/s)
Max Tilt Angle: 35°
Operating Temperature:
-10° to 40° C (14° to 104° F)
Global Navigation Satellite System:
GPS + Galileo + BeiDou
Hovering Accuracy Range:
Vertical:
±0.1 m (with vision positioning)
±0.5 m (with GNSS positioning)
Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with high-precision positioning system)
Internal Storage:
Mavic 3 Pro: 8 GB (approx. 7.9GB available space)
CAMERA
Image Sensor:
Hasselblad Camera: 4/3 CMOS, Effective Pixels: 20 MP
Medium Tele Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective Pixels: 12 MP
Lens:
Hasselblad Camera:
FOV: 84°
Format Equivalent: 24mm
Aperture: f/2.8-f/11
Focus: 1 m to ∞
Medium Tele Camera:
FOV: 35°
Format Equivalent: 70mm
Aperture: f/2.8
Focus: 3 m to ∞
Tele Camera:
FOV: 15°
Format Equivalent: 166mm
Aperture: f/3.4
Focus: 3 m to ∞
ISO Range:
Video
Normal and Slow Motion:
100-6400 (Normal)
400-1600 (D-Log)
100-1600 (D-Log M)
100-1600 (HLG)
Night:
800-12800 (Normal)
Photo:
100-6400
Shutter Speed:
Hasselblad Camera: 8-1/8000 s
Medium Tele Camera: 2-1/8000 s
Tele Camera: 2-1/8000 s
Max Image Size:
Hasselblad Camera: 5280×3956
Medium Tele Camera: 8064×6048
Tele Camera: 4000×3000
Still Photography Modes:
Hasselblad Camera:
Single Shot: 20 MP
Burst Shooting: 20 MP, 3/5/7 frames
Automatic Exposure Bracketing (AEB): 20 MP, 3/5 frames at 0.7 EV step
Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s
Medium Tele Camera:
Single Shot: 12 MP or 48 MP
Burst Shooting: 12 MP or 48 MP, 3/5/7 frames
Automatic Exposure Bracketing (AEB): 12 MP or 48 MP, 3/5 frames at 0.7 EV step
Timed:
12 MP: 2/3/5/7/10/15/20/30/60 s
48 MP: 7/10/15/20/30/60 s
Tele Camera:
Single Shot: 12 MP
Burst Shooting: 12 MP, 3/5/7 frames
Automatic Exposure Bracketing (AEB): 12 MP, 3/5 frames at 0.7 EV step
Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s
Photo Format: JPEG/DNG (RAW)
Video Resolution:
Hasselblad Camera
Apple ProRes 422 HQ
Apple ProRes 422
Apple ProRes 422 LT
5.1K: 5120×
[email protected]/25/30/48/50fps
DCI 4K: 4096×
[email protected]/25/30/48/50/60/120*fps
4K: 3840×
[email protected]/25/30/48/50/60/120*fps
H.264/H.265
5.1K: 5120×
[email protected]/25/30/48/50fps
DCI 4K: 4096×
[email protected]/25/30/48/50/60/120*fps
4K: 3840×
[email protected]/25/30/48/50/60/120*fps
FHD: 1920×
[email protected]/25/30/48/50/60/120*/200*fps
* Recording frame rates. The corresponding video plays as slow-motion video.
Medium Tele Camera:
Apple ProRes 422 HQ
Apple ProRes 422
Apple ProRes 422 LT
4K: 3840×
[email protected]/25/30/48/50/60fps
H.264/H.265:
4K: 3840×
[email protected]/25/30/48/50/60fps
FHD: 1920×
[email protected]/25/30/48/50/60fps
Tele Camera:
Apple ProRes 422 HQ
Apple ProRes 422
Apple ProRes 422 LT
4K: 3840×
[email protected]/25/30/48/50/60fps
H.264/H.265:
4K: 3840×
[email protected]/25/30/50/60fps
FHD: 1920×
[email protected]/25/30/50/60fps
Video Format:
MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
MOV (Apple ProRes 422 HQ/422/422 LT)
Max Video Bitrate:
H.264/H.265: 200 Mbps
Apple ProRes 422 HQ: 3772 Mbps
Apple ProRes 422: 2514 Mbps
Apple ProRes 422 LT: 1750 Mbps
Supported File System: exFAT
Color Mode and Sampling Method:
Hasselblad Camera:
Normal:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
8-bit 4:2:0 (H.264/H.265)
D-Log:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
10-bit 4:2:0 (H.264/H.265)
HLG/D-Log M:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
10-bit 4:2:0 (H.265)
Medium Tele Camera:
Normal:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
8-bit 4:2:0 (H.264/H.265)
HLG/D-Log M:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
10-bit 4:2:0 (H.265)
Tele Camera:
Normal:
10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT)
8-bit 4:2:0 (H.264/H.265)
Digital Zoom (only in Normal Video Mode and Explore Mode)
Hasselblad Camera: 1-3x
Medium Tele Camera: 3-7x
Tele Camera: 7-28x
GIMBAL
Stabilization:
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range:
Tilt: -140° to 50°
Roll: -50° to 50°
Pan: -23° to 23°
Controllable Range:
Tilt: -90° to 35°
Pan: -5° to 5°
Max Control Speed (tilt): 100°/s
Angular Vibration Range:
Hovering Without Wind: ±0.001°
Normal Mode: ±0.003°
Sport Mode: ±0.005°
RC PRO CONTROLLER
Video Transmission System: O3+
Max Transmission Distance (unobstructed, free of interference):
15 km (FCC); 8 km (CE/SRRC/MIC)
Operating Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Antennas:
4 Antennas, 2T4R
Transmitter Power (EIRP):
2.4 GHz: =33 dBm (FCC); =20 dBm (CE/SRRC/MIC)
5.8 GHz: =33 dBm (FCC); =14 dBm (CE); =23 dBm (SRRC)
Wi-Fi protocol:
802.11a/b/g/n/ac/ax Support 2×2 MIMO Wi-Fi
Operating Frequency
2.400GHz-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP):
2.4 GHz: =26 dBm (FCC); =20 dBm (CE/SRRC/MIC)5.8 GHz: =26 dBm (FCC/SRRC); =14 dBm (CE)
Bluetooth Protocol: Bluetooth 5.1
Operating Frequency
2.400-2.4835 GHz
Transmitter Power (EIRP): ≤8 dbm
Screen Resolution: 1920×1080
Dimensions: 5.5 inches
Frame Rate: 60 fps
Brightness: 1000 nits
Touch Control: 10-point multi-touch
Battery: Li-ion (5000 mAh @ 7.2 V)
Charging Type: Recommended to be charged with USB charger at 12 V or 15 V
Rated Power: 12 W
Storage Capacity:
32GB internal + expandable storage via microSD card
Charging Time:
2 hours (with USB charger at 12 V), 1.5 hours (with USB charger at 15 V)
Operating Time: 3 hours
Video Output Port: Mini-HDMI port
Operating Temperature:
-10° to 40°C (14° to 104° F)
Storage Temperature Range:
Less than one month: -30° to 60° C (-22° to 140° F)
One to three months: -30° to 45° C (-22° to 113° F)
Three to six months: -30° to 35° C (-22° to 95° F)
More than six months: -30° to 25° C (-22° to 77° F)
Charging Temperature:
5° to 40° C (41° to 104° F)
Supported Aircraft Models:
DJI Mavic 3, DJI Mavic 3 Cine, DJI Air 2S
GNSS: GPS + Galileo + GLONASS
Dimensions:
183.27×137.41×47.6 mm (antennas folded, controllers not mounted)
183.27×203.35×59.84 mm (antennas unfolded, controllers mounted)
Weight: Approx. 680 g
Model: RM510
Supported SD Cards:
SanDisk Extreme PRO 64GB V30 A2 microSDXCSanDisk High Endurance 64GB V30 microSDXCSanDisk Extreme 128GB V30 A2 microSDXCSanDisk Extreme 256GB V30 A2 microSDXCSanDisk Extreme 512GB V30 A2 microSDXCLexar 667x 64GB V30 A2 microSDXCLexar High-Endurance 64GB V30 microSDXCLexar High-Endurance 128GB V30 microSDXCLexar 667x 256GB V30 A2 microSDXCLexar 512GB V30 A2 microSDXCSamsung EVO 64GB V30 microSDXCSamsung EVO Plus 128GB V30 microSDXCSamsung EVO Plus 256GB V30 microSDXCSamsung EVO Plus 512GB V30 microSDXCKingston 128GB V30 microSDXC
BATTERY
Capacity: 5000 mAh
Weight: 335.5 g (11.83 oz)
Nominal Voltage: 15.4 V
Max Charging Voltage: 17.6 V
Type: Li-ion 4S
Energy: 77 Wh
Charging Temperature:
5° to 40° C (41° to 104° F)
Charging Time:
Approx. 96 minutes
Use the included data cable of the DJI 65W Portable Charger.
Approx. 70 minutes:
Use the DJI 100W USB-C Power Adapter and DJI Mavic 3 Series 100W Battery Charging Hub.
VIDEO TRANSMISSION
Video Transmission System: O3+
Live View Quality:
Remote Controller:
1080p/30fps, 1080p/60fps
Operating Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Transmitter Power (EIRP):
2.4 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)
5.8 GHz:
< 33 dBm (FCC)
< 30 dBm (SRRC)
< 14 dBm (CE)
Max Transmission Distance (unobstructed, free of interference):
FCC: 15 km (9.32 miles)
CE: 8 km (4.97 miles)
SRRC: 8 km (4.97 miles)
MIC: 8 km (4.97 miles)
Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminders in the DJI Fly app.
Max Transmission Distance (unobstructed, with interference):
Strong Interference: Urban landscape, approx. 1.5-3 km (0.93-1.86 miles)
Medium Interference: Suburban landscape, approx. 3-9 km (1.86-5.59 miles)
Low Interference: Suburb/seaside, approx. 9-15 km (5.59-9.32 miles)
Data tested under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Transmission Distance (obstructed, with interference):
Low Interference and Obstructed by Buildings: approx. 0-0.5 km (0-0.31 miles)
Low Interference and Obstructed by Trees: approx. 0.5-3 km (0.31-1.86 miles)
Data tested under FCC standard in environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Download Speed:
O3+:
5.5 MB/s (with DJI RC-N1 Remote Controller)
15 MB/s (with DJI RC Pro)
5.5 MB/s (with DJI RC)
Wi-Fi 6: 80 MB/s*
* Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, with footage saved to the internal storage. Download speeds may vary depending on the actual conditions.
Lowest Latency:
130 ms (with DJI RC-N1 Remote Controller)
120 ms (with DJI RC Pro)
130 ms (with DJI RC)
Depending on the actual environment and mobile device.
Antenna: 4 antennas, 2T4R
SENSING SYSTEM
Sensing Type:
Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Forward:
Measurement Range:
0.5-20 m
Detection Range:
0.5-200 m
Effective Sensing Speed:
Flight Speed = 33.5 mph (15 m/s)
FOV:
Horizontal 90°, Vertical 103°
Backward
Measurement Range:
0.5-16 m
Effective Sensing Speed:
Flight Speed = 26.8 mph (12 m/s)
FOV:
Horizontal 90°, Vertical 103°
Lateral:
Measurement Range:
0.5-25 m
Effective Sensing Speed:
Flight Speed = 33.5 mph (15 m/s)
FOV:
Horizontal 90°, Vertical 85°
Upward:
Measurement Range:
0.2-10 m
Effective Sensing Speed:
Flight Speed = 13.42 mph (6 m/s)
FOV:
Front and Back 100°, Left and Right 90°
Downward:
Measurement Range:
0.3-18 m
Effective Sensing Speed:
Flight Speed = 13.42 mph (6 m/s)
FOV:
Front and Back 130°, Left and Right 160°
Operating Environment
Forward, Backward, Left, Right, and Upward:
surfaces with discernible patterns and adequate lighting (lux > 15)
Downward:
surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 15)
CHARGER
Input:
DJI 65W Portable Charger:
100-240 V (AC), 50-60 Hz, 2 A
DJI 100W USB-C Power Adapter:
100-240 V (AC), 50-60 Hz, 2.5 A
Output
DJI 65W Portable Charger:
USB-C:
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 4.3 A
20 V, 3.25 A
5-20 V, 3.25 A
USB-A:
5 V, 2 A
DJI 100W USB-C Power Adapter:
Max 100 W (total)
When both ports are used, the max output power of one port is 82 W, and the charger will dynamically allocate the output power of the two ports according to the power load.
Rated Power:
DJI 65W Portable Charger: 65 W
DJI 100W USB-C Power Adapter: 100 W
BATTERY CHARGING HUB
Input:
USB-C: 5-20 V, max 5 A
Output:
Battery Port: 12-17.6 V, max 5 A
Rated Power
Battery Charging Hub: 65 W
Battery Charging Hub (100W): 100 W
Charging Type:
Three batteries charged in sequence.
Compatibility: DJI Mavic 3 Intelligent Flight Battery
CAR CHARGER
Input:
Car Power Input:
12.7-16 V, 6.5 A, rated voltage 14 V (DC)
Output:
USB-C:
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 4.3 A
20 V, 3.25 A
5-20 V, 3.25 A
USB-A:
5 V, 2 A
Rated Power: 65 W
Charging Temperature:
5° to 40° C (41° to 104° F)
STORAGE
Recommended microSD Cards:
Lexar 1066x 64GB V30 A2 microSDXC
Lexar 1066x 128GB V30 A2 microSDXC
Lexar 1066x 256GB V30 A2 microSDXC
Lexar 1066x 512GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk High Endurance 128GB V30 microSDXC
SanDisk High Endurance 256GB V30 microSDXC
Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas Go! Plus 256GB V30 A2 microSDXC
Kingston Canvas Go! Plus 512GB V30 A2 microSDXC
Samsung EVO Plus 512GB V30 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC
Samsung PRO Plus 512GB V30 A2 microSDXC
