AIRCRAFT
Weight (With Propellers, No Accessories):
DJI Mavic 3T: 2.03 lbs (920 g)
Max Takeoff Weight:
DJI Mavic 3T: 2.31 lbs (1,050 g)
Dimensions:
Folded (without propellers): 221×96.3×90.3 mm (L×W×H)
Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)
Diagonal Distance: 380.1 mm
Max Ascent Speed:
13.4 mph (6 m/s) (Normal Mode)
17.9 mph (8 m/s) (Sport Mode)
Max Descent Speed:
13.4 mph (6 m/s) (Normal Mode)
13.4 mph (6 m/s) (Sport Mode)
Max Flight Speed (at sea level, no wind):
Normal Mode: 33.5 mph (15 m/s) (Normal Mode)
Sport Mode:
Forward: 47 mph (21 m/s)
Side: 44.7 mph (20 m/s)
Backward: 42.5 mph (19 m/s)
Max Wind Speed Resistance: 26.8 mph (12 m/s)
Max Take-off Altitude Above Sea Level:
19,685 ft (6000 m) (without payload)
Max Flight Time (no wind): 45 minutes
Max Hover Time (no wind): 38 minutes
Max Flight Distance: 19.8 mi (32 km)
Max Tilt Angle:
30° (Normal Mode)
35° (Sport Mode)
Max Angular Velocity: 200°/s
GNSS:
GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)
Hovering Accuracy:
Vertical: ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
Horizontal: ±0.3 m (with Vision System); ±0.5 m (with High-Precision Positioning System); ±0.1 m (with RTK)
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Internal Storage: N/A
Motor Model: 2008
Propeller Model: 9453F Propellers for Enterprise
Beacon: Built into the aircraft
WIDE ANGLE CAMERA
Sensor:
1/2-inch CMOS, Effective pixels: 48 MP
Lens:
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8
Focus: 1 m to ∞
ISO Range:
100-25600
Shutter Speed:
Electronic Shutter: 8-1/8000 s
Max Image Size:
8000×6000
Still Photography Modes:
Single: 12 MP/48 MP
Timed: 12 MP/48 MP
JPEG: 2/3/5/7/10/15/20/30/60 s*
Panorama: 12 MP (raw image); 100 MP (stitched image)
Smart Low-light Shooting: 12 MP
* Shooting 48MP photo does not support 2s interval
Video Resolution:
H.264
4K: 3840×
[email protected]
FHD: 1920×
[email protected]
Bitrate:
4K: 85 Mbps
FHD: 30 Mbps
Supported File Formats: exFAT
Photo Format: JPEG
Video Format: MP4 (MPEG-4 AVC/H.264)
TELE CAMERA
Sensor: 1/2-inch CMOS, Effective pixels: 12 MP
Lens:
FOV: 15°
Format Equivalent: 162 mm
Aperture: f/4.4
Focus: 3 m to ∞
ISO Range: 100-25600
Shutter Speed:
Electronic Shutter: 8-1/8000 s
Max Image Size: 4000×3000
Photo Format: JPEG
Video Format: MP4 (MPEG-4 AVC/H.264)
Still Photography Modes:
Single: 12 MP
Timed: 12 MP
JPEG: 2/3/5/7/10/15/20/30/60 s
Smart Low-light Shooting: 12 MP
Video Resolution:
H.264
4K: 3840×
[email protected]
FHD: 1920×
[email protected]
Bitrate:
4K: 85 Mbps
FHD: 30 Mbps
Digital Zoom: 8x (56x hybrid zoom)
THERMAL CAMERA
Thermal Imager: Uncooled VOx Microbolometer
Pixel Pitch: 12 µm
Frame Rate: 30 Hz
Lens:
DFOV: 61°
Format Equivalent: 40 mm
Aperture: f/1.0
Focus: 5 m to ∞
Sensitivity: =50
[email protected]
Temperature Measurement Method:
Spot Meter, Area Measurement
Temperature Measurement Range:
-20° to 150° C (-4° to 302° F, High Gain Mode)
0° to 500° C (32° to 932° F, Low Gain Mode)
Palette:
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2
Photo Format:
JPEG (8-bit)
R-JPEG (16-bit)
Video Resolution: 640×
[email protected]
Bitrate: 6 Mbps
Video Format:
MP4 (MPEG-4 AVC/H.264)
Still Photography Modes:
Single: 640×512
Timed: 640×512
JPEG: 2/3/5/7/10/15/20/30/60 s
Digital Zoom: 28x
Infrared Wavelength: 8-14 µm
Infrared Temperature Measurement Accuracy:
±2° C or ±2% (using the larger value)
GIMBAL
Stabilization: 3-axis (tilt, roll, pan)
Mechanical Range:
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -27° to 27°
Controllable Range:
Tilt: -90° to 35°
Pan: Not controllable
Max Control Speed (tilt): 100°/s
Angular Vibration Range: ±0.007°
SENSING SYSTEM
Type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.
Forward:
Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed =15 m/s
FOV: Horizontal 90°, Vertical 103°
Backward:
Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed =12 m/s
FOV: Horizontal 90°, Vertical 103°
Lateral:
Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed =15 m/s
FOV: Horizontal 90°, Vertical 85°
Upward:
Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed =6 m/s
FOV: Front and Back 100°, Left and Right 90°
Downward:
Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed =6 m/s
FOV: Front and Back 130°, Left and Right 160°
Operating Environment:
Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15)
Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)
VIDEO TRANSMISSION
Video Transmission System: DJI O3 Enterprise Transmission
Live View Quality: Remote Controller: 1080p/30fps
Operating Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Max Transmission Distance (Unobstructed, Free of Interference):
FCC: 9.32 mi (15 km)
CE: 4.97 mi (8 km)
SRRC: 4.97 mi (8 km)
MIC: 4.97 mi (8 km)
Max Transmission Distance (Obstructed):
Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
Max Download Speed:
15 MB/s (with DJI RC Pro Enterprise)
Latency (depending on environmental conditions and mobile device): Approx. 200 ms
Antenna: 4 Antennas, 2T4R
Transmission Power (EIRP):
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
DJI RC PRO ENTERPRISE
Video Transmission System: DJI O3 Enterprise Transmission
Max Transmission Distance (unobstructed, free of interference):
FCC: 9.32 mi (15 km)
CE/SRRC/MIC: 4.97 mi (8 km)
Video Transmission Operating Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Antenna: 4 Antennas, 2T4R
Video Transmission Transmitter Power (EIRP):
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)
Wi-Fi Protocol:
802.11 a/b/g/n/ac/ax
Support 2×2 MIMO Wi-Fi
Wi-Fi Operating Frequency:
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Transmitter Power (EIRP):
2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth Protocol: Bluetooth 5.1
Bluetooth Operating Frequency: 2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP): < 10 dBm
Screen Resolution: 1920×1080
Screen Size: 5.5 inches
Screen: 60 fps
Brightness: 1,000 nits
Touchscreen Control: 10-point multi-touch
Battery: Li-ion (5000 mAh @ 7.2 V)
Charging Type:
Recommended to be charged with the included DJI USB-C Power Adapter (100W) or USB charger at 12 V or 15 V
Rated Power: 12 W
Storage Capacity: Internal Storage (ROM): 64 GB. Supports a microSD card for expanded capacity.
Charging Time:
Approx. 1 hour 30 minutes (with the included DJI USB-C Power Adapter (100W) only charging the remote controller or a USB charger at 15 V)
Approx. 2 hours (with a USB charger at 12 V)
Approx. 2 hours 50 minutes (with the included DJI USB-C Power Adapter (100W) charging the aircraft and remote controller simultaneously)
Operating Time: Approx. 3 hours
Video Output Port: Mini-HDMI port
Operating Temperature Range:
-10° to 40° C (14° to 104° F)
Storage Temperature:
-30° to 60° C (-22° to 140° F) (within one month)
-30° to 45° C (-22° to 113° F) (one to three months)
-30° to 35° C (-22° to 95° F) (three to six months)
-30° to 25° C (-22° to 77° F) (more than six months)
Charging Temperature:
5° to 40° C (41° to 104° F)
Supported DJI Aircraft:
DJI Mavic 3E
DJI Mavic 3T
GNSS:
GPS+Galileo+GLONASS
Dimensions:
Antennas folded and controller sticks unmounted:
183.27×137.41×47.6 mm (L×W×H)
Antennas unfolded and controller sticks mounted:
183.27×203.35×59.84 mm (L×W×H)
Weight: Approx. 1.49 lbs (680 g)
Model: RM510B
STORAGE
Supported Memory Cards:
Aircraft:
U3/Class10/V30 or above is required. A list of recommended microSD cards can be found below.
Recommended microSD Cards:
Remote Controller:
SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 667x 64GB V30 A2 microSDXC
Lexar High-Endurance 64GB V30 microSDXC
Lexar High-Endurance 128GB V30 microSDXC
Lexar 667x 256GB V30 A2 microSDXC
Lexar 512GB V30 A2 microSDXC
Samsung EVO Plus 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Samsung EVO Plus 512GB V30 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Aircraft:
SanDisk Extreme 32GB V30 A1 microSDHC
SanDisk Extreme PRO 32GB V30 A1 microSDHC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 1066x 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas React Plus 64GB V90 A1 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Kingston Canvas React Plus 256GB V90 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC
INTELLIGENT FLIGHT BATTERY
Capacity: 5000 mAh
Standard Voltage: 15.4 V
Max Charging Voltage: 17.6 V
Type: LiPo 4S
Chemical System: LiCoO2
Energy: 77 Wh
Weight: 335.5 g
Charging Temperature:
5° to 40° C (41° to 104° F)
CHARGER
Input: 100-240 V (AC Power), 50-60 Hz, 2.5 A
Output Power: 100 W
Output:
Max. 100 W (total)
When both ports are used, the maximum output power of each interface is 82 W, and the charger will dynamically allocate the output power of the two ports according to the load power.
CHARGING HUB
Input: USB-C: 5-20 V, 5.0 A
Output:
Battery Port: 12-17.6 V, 8.0 A
Rated Power: 100 W
Charging Type:
Three batteries charged in sequence
Charging Temperature Range:
5° to 40° C (41° to 104° F)
RTK MODULE
Dimensions: 50.2×40.2×66.2 mm (L×W×H)
Weight: 24±2 g
Interface: USB-C
Power:
Approx. 1.2 W
RTK Positioning Accuracy:
RTK Fix:
Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm
SPEAKER
Dimensions:
114.1×82.0×54.7 mm (L×W×H)
Weight: 85±2 g
Interface: USB-C
Rated Power: 3 W
Max Volume: 110 dB @ 1 m
Effective Broadcast Distance: 100 m @ 70 dB
Bit Rate: 16 Kbps/32 Kbps
Operating Temperature Range:
-10° to 40° C (14° to 104° F)
OTHER
Notes:
[1] The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
[2] Maximum speed in Sport mode is 19m/s when operating in EU regions.
[3] Max wind speed resistance during takeoff and landing.
[4] Measured with Mavic 3 Enterprise Series flying at a constant speed of 32.4 kph in a windless environment at sea level until the battery reached 0%. Data is for reference only. Please pay attention to RTH reminders in the DJI Pilot 2 app during flight.
[5] DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or laser beams. Otherwise, the camera sensor may be burned, leading to permanent damage.
[6] In some countries and regions, the 5.8 and 5.1GHz frequencies are prohibited, or the 5.1GHz frequency is only allowed for indoor use. Check local laws and regulations for more information.
[7] Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights (with no payload) under each standard. During your flight, please pay attention to RTH reminders in the DJI Pilot 2 app.
[8] Data tested under different standards in unobstructed environments with typical interference. Uses for reference purposes only and provides no guarantee as to the actual flight distance.
[9] Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. With footage saved on the officially recommended microSD cards. Download speeds may vary depending on actual conditions.
[10] Will support more DJI aircraft in the future. Visit the official website for the latest information.
[11] Data was measured in a controlled environment and is for reference only. Actual use experience may vary depending on software version, sound source, specific environment, and other conditions.
