AIRCRAFT
Model: QF2W4K
Takeoff Weight: Approx. 410 g
Dimensions (L×W×H): 7.08x7.08x3.14 in (180×180×80 mm)
Diagonal Distance: 4.72 in (120 mm)
Max Ascent Speed:
13.42 mph (6 m/s) (Normal Mode, Sport Mode)
Max Descent Speed:
13.42 mph (6 m/s) (Normal Mode, Sport Mode)
Max Speed:
17.9 mph (8 m/s) (Normal Mode)
31.3 mph (14 m/s) (Sport Mode)
60.4 mph (27 m/s) (Manual Mode)
Maximum Takeoff Altitude: 16,404 ft (5000 m)
Max Hover Time: Approx. 18 mins
Max Flight Distance: 7.2 mi (11.6 km)
Max Wind Speed Resistance:
23.9 mph (10.7 m/s) (Level 5)
Operating Temperature Range:
-10° to 40° C (14° to 104° F)
Transmission Power (EIRP):
FCC: < 33 dBm
CE: < 14 dBm
SRRC: < 30 dBm
Antennas:
Dual Antennas, 2T2R
GNSS:
GPS + Galileo + BeiDou
Hovering Accuracy Range:
Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GNSS Positioning)
Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GNSS Positioning)
Supported SD Cards: microSD (up to 256 GB)
Recommended microSD Cards:
SanDisk Extreme U3 V30 A1 32GB microSDXC
SanDisk Extreme Pro U3 V30 A1 32GB microSDXC
Kingston Canvas Go!Plus U3 V30 A2 64GB microSDXC
Kingston Canvas React Plus U3 V90 A1 64GB microSDXC
Kingston Canvas React Plus U3 V90 A1 128GB microSDXC
Kingston Canvas React Plus U3 V90 A1 256GB microSDXC
Samsung PRO Plus V30 U3 V30 A2 256GB microSDXC
Internal Storage: 20 GB
CAMERA
Sensor: 1/1.7-inch CMOS
Effective Pixels: 48 MP
Lens:
FOV: 155°
Equivalent Focal Length: 12.7 mm
Focal Length: 2.34 mm
Aperture: f/2.8
Focus Mode: FF
Focus Range: 0.6 m to ∞
ISO Range:
100-6400 (Auto)
100-25600 (Manual)
Shutter Speed:
Video: 1/8000-1/50 s
Photo: 1/8000-1/50 s
Still Photography Mode: Single Shot
Max Image Size: 4000×3000
Photo Format: JPEG
Video Resolution (with DJI Goggles 2):
[email protected]/60fps
[email protected]/60/100fps
[email protected]/60/100fps
With DJI FPV Goggles V2:
[email protected]/60fps
[email protected]/60/100/120fps
[email protected]/60/100/120fps
Video Format: MP4
Max Video Bitrate: 150 Mbps
Color Mode: Standard, D-Cinelike
EIS:
Supports RockSteady and HorizonSteady. Can be disabled.
Distortion Correction:
Supports Normal Mode, Wide Mode, and Ultra Wide Mode
Supported File System: exFAT (recommended), FAT32
GIMBAL
Mechanical Range:
Tilt: -95° to 75°
Controllable Range:
Tilt: -80° to +65°
Stabilization: Single-Axis (tilt)
Max Control Speed: 60°/s
Angular Vibration Range: ±0.01°
Electronic Roll Axis:
Real-time screen correction is unavailable during recording, but can be applied to the footage recorded on the drone.
SENSING SYSTEM
Downward (Binocular Vision and ToF):
ToF Effective Measurement Height: 32.8 ft (10 m)
Precise Hovering Range: 1.6-32.8 ft (0.5-10 m)
Vision Sensor Hovering Range: 1.6-66 ft (0.5-20 m)
Operating Environment:
Diffuse reflective surfaces with a clear pattern > 20% (such as walls, trees, or people). Adequate lighting (lux > 15, normal indoor lighting conditions)
INTELLIGENT FLIGHT BATTERY
Battery Capacity: 2420 mAh
Voltage: 14.76 V
Charging Voltage Limit: 17 V
Type: Li-ion
Chemical System: LiNiMnCoO2
Energy: 35.71
[email protected]
Discharge Rate: Typical: 7C
Weight: Approx. 162 g
Charging Temperature Range:
5° to 40° C (41° to 104° F)
VIDEO TRANSMISSION
Communication Frequency:
2.400-2.4835 GHz (RX only)
5.725-5.850 GHz (RX and TX)
Communication Bandwidth: Max 40 MHz
Live View Quality and Latency:
With DJI FPV Goggles V2:
810p/120fps Video Transmission Quality: The video transmission latency is lower than 28 ms.
810p/60fps Video Transmission Quality: The video transmission latency is lower than 40 ms.
With DJI Goggles 2:
1080p/100fps Video Transmission Quality: The video transmission latency is as low as 30 ms.
1080p/60fps Video Transmission Quality: The video transmission latency is as low as 40 ms.
Max Video Transmission Bitrate: 50 Mbps
Max Video Transmission Range: 6.21 mi (10 km) (FCC), 1.24 mi (2 km) (CE), 3.72 mi (6 km) (SRRC)
Audio Transmission: N/A
DJI GOGGLES 2
Model: RCDS18
Weight: Approx. 290 g (headband included)
Dimensions (L×W×H):
With antennas folded: 167.40×103.90×81.31 mm
With antennas unfolded: 196.69×103.90×104.61 mm
Screen Size (single screen): 0.49-inch
Resolution (single screen): 1920×1080
Refresh Rate: Up to 100 Hz
Interpapillary Distance Range: 56-72 mm
Diopter Adjustment Range: -8.0 D to +2.0 D
FOV (single screen): 51°
Communication Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Transmission Power (EIRP):
2.4 GHz: < 30 dBm (FCC), < 20 dBm (CE/SRRC/KC)
5.8 GHz [4]: < 30 dBm (FCC), < 23 dBm (SRRC), < 14 dBm (CE/KC)
Wi-Fi Protocol:
Wi-Fi 802.11b/a/g/n/ac
Wi-Fi Communication Frequency
2.400-2.4835 GHz
5.150-5.250 GHz (indoor use only)
5.725-5.850 GHz
Wi-Fi Transmission Power (EIRP):
2.4 GHz: < 20 dBm (FCC/CE/SRRC/KC)
5.1 GHz [8]: < 20 dBm (FCC/CE/KC)
5.8 GHz [4]: < 20 dBm (FCC/SRRC/KC), < 14 dBm (CE)
Bluetooth Protocol: Bluetooth 5.2
Bluetooth Communication Frequency: 2.400-2.4835 GHz
Bluetooth Transmission Power (EIRP): < 8 dBm
Max Video Transmission Bitrate: 50 Mbps
Video Recording Format: MOV
Supported Video and Audio Playback Formats:
MP4 and MOV (video coding formats: H.264 and H.265; audio format: ACC, PCM)
Wi-Fi Wireless Streaming: Supports DLNA Protocol
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Power Input: DJI Goggles 2 Battery
Supported SD Cards: microSD (up to 256 GB)
DJI GOGGLES 2 BATTERY
Capacity: 1800 mAh
Voltage: 7-9 V (1.5 A)
Type: Li-ion
Chemical System: LiNiMnCoO2
Energy: 18 Wh
Charging Temperature Range:
0° to 45° C (32° to 113° F)
Max Charging Power:
12.6 W (5 V/2 A, 9 V/1.4 A)
Weight: Approx. 122 g
Dimensions (L×W×H):
73.04×40.96×26 mm
Operating Time: Approx. 2 hours
DJI MOTION CONTROLLER
Model: FC7BMC
Weight: Approx. 167 g
Communication Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz [4]
Transmission Power (EIRP):
2.4 GHz: = 28.5 dBm (FCC), = 20 dBm (CE/SRRC)
5.8 GHz [4]: = 31.5 dBm (FCC), = 19 dBm (SRRC), = 14 dBm (CE)
Operating Temperature Range:
-10° to 40° C (14° to 104° F)
Operating Time: Approx. 5 hours
DJI FPV REMOTE CONTROLLER 2 (NOT INCLUDED)
Model: FC7BGC
Weight: Approx. 346 g
Communication Frequency:
2.400-2.4835 GHz
5.725-5.850 GHz
Transmission Power (EIRP):
2.4 GHz: = 28.5 dBm (FCC), = 20 dBm (CE/SRRC)
5.8 GHz [4]: = 31.5 dBm (FCC), = 19 dBm (SRRC), = 14 dBm (CE)
Dimensions (L×W×H): 190×140×51 mm
Operating Time: Approx. 9 hours
Operating Temperature Range:
-10° to 40° C (14° to 104° F)
Charging Time: 2.5 hours
