Autel Dragonfish Pro VTOL Fixed-Wing Surveillance Drone

The Autel Dragonfish Pro package is an amazing aircraft featuring the following capabilities:
- 180 Minute Flight Time (Longest flight time with load)
- 3 Minute Quick Assembly
- 4K 50x Optical Zoom
- 111 mph Max Speed (180km/h)
- 18.6 Mile Transmission Range
- 5 Second System Boot and Self Check


Autel Dragonfish Series Safety Mechanisms
GPS Loss Protection - If GPS signal is lost, the Dragonfish will automatically land at it's current location.
Low Battery Protection - When the Dragonfish battery reached the set threshold, the pilot will receive a low battery warning, and the aircraft will start to return home automatically. Once the battery level has reached 15%, the pilot will receive a critical power warning, and the aircraft will automatically land on the spot.
Lost Signal Protection - If communication between the aircraft and the ground station is interrupted, the aircraft will use its GPS signal to return home automatically.


Safety and Redundancy
1. Built Tough: The Aircraft's composite outer shell and carbon fiber core gives the aircraft and wind resistance rating of level 6 and IP43 weather resistance to handle complex environments with ease.
2. Backup Modules: The Dragonfish battery, barometer, positioning system, compass, and IMU all have backup modules to ensure flight safety.
3. Autel Robotics' superior flight control platform guarantees stability and reliability in every flight.
4. Automatic Transition: Dragonfish will automatically transition to multi-rotor mode if adverse conditions cause fixed winged flight to stall or become unsustainable. The dragonfish can automatically choose which mode to fly for the best performance.
5. Internal Communication: Dual-redundant CAN bus communication protects the aircraft from electromagnetic interference and enables the rudder surface and motor status to be monitored in real time.
6. High Quality Sensors: Integrated airspeed velocity sensor monitor the environment in real time, even while buffeted by snow or ice.
7. Attentive AI: Vigilant AI continuously self-checks the system to prevent faults before they occur.

Intelligence and Autonomy: Simplify mission tasks with the Dragonfish's wide array of automated functions
Using Autel's advanced flight control technology and intelligent AI, the Dragonfish can tackle even the most complex operations.


One Button Takeoff and Landing
Streamline mission tasks with the click of a single button. The easy to use interface will ensure that you save time while you are out in the field.


AI Highspeed Tracking Capability
Advanced Artificial Intelligence and algorithms allow for accurate tracking of subjects at high speeds.


Point of Interest Mode
Accurately circle and collect data on a point of interest.


Adaptive Tracking
The Autel Dragonfish features adaptive tracking algorithms that allow it to read topographical data and adjust it's altitude accordingly.


Advanced Mission Planning
The Dragonfish features advanced mission planning software that allows for more efficiency while gathering accurate data.

Other Notable Features

• The battery, IMU, barometer, compass and positioning system all have backup modules for redundancy to ensure safety.
• Autel's superior flight control platform guarantees reliability and stability with every flight.
• The Dragonfish features an IP43 rating. This platform has a high strength composite body, level 6 wind resistance allows the Dragonfish to handle complex environments with ease.
• Dual-redundant CAN bus communication enables real-time monitoring of the rudder surface and motor status which protects the aircraft from strong electromagnetic interference.
• The Dragonfish uses Artificial Intelligence to continuously self check it's system to prevent accidents and faults before they occur.
• Integrated airspeed velocity sensors enable the Dragonfish to monitor it's environment in real-time. It is impervious to snow or ice.
• The aircraft will automatically transition to multi-rotor mode in the event of adverse conditions where fixed wing flight may stall or be unsustainable.

Interchangeable Payload System
Tackle any operation with a variety of payload options that can be easily swapped to suit mission needs. Dragonfish payloads are designed to be interchangeable between aircraft classes to maximize the value and enhance the mission capability of the system.

DG-Z2:
- For Dragonfish Lite/Standard/Pro
- 4K 20x Optical Zoom
- 12 Megapixel Wide-Angle
- 3 Axis Stabilized Gimbal System

DG-M1
- For Dragonfish Lite/Standard/Pro
- 1 Visible Light Sensor (12 Megapixels)
- 6 Multispectral Sensors
- 3 Axis Stabilized Gimbal System

DG-L20T
- For Dragonfish Standard/Pro
- 4x 20x Optical Zoom
- 12 Megapixel Wide-Angle
- 640x512 High Resolution Infrared
- Laser Distance Measurement Radar
- 3 Axis Stabilized Gimbal System

DG-L50T
- For Dragonfish Pro
- 4K 50x Optical Zoom
- 12 Megapixel Wide-Angle
- 1280x1024 High Resolution Infrared
- Laser Distance Measurement Radar
- 3 Axis Stabilized Gimbal System

DG-T3
- For Dragonfish Lite/Standard/ Pro
- 4K 20x Optical Zoom
- 12 Megapixel Wide-Angle
- 640x512 High Resolution Infrared
- 3 Axis Stabilized Gimbal System

DG-T3H
- For Dragonfish Lite/Standard/ Pro
- 12 Megapixel Wide-Angle
- 1280x1024 High Resolution Infrared
- Laser Distance Measurement Radar
- 3 Axis Stabilized Gimbal System

The Autel Dragonfish's powerful platform allows it to excel in a wide range of commercial applications. This includes but is not limited to:
- Public Safety
- Energy
- Fire Fighting and Prevention
- Traffic Monitoring and Management
- Agriculture
- Coastal Overwatch and Security

On Board Dual RTK
The Autel Robotics Dragonfish is equipped with 2 RTK modules for added redundancy. By integrating the GNSS Base Station with the RTK modules, the Dragonfish can achieve centimeter accuracy, precise headings and strong anti-magnetic interference capabilities. These modules back up one another and this greatly improves the quality of image metadata for photogrammetry and increases flight precision and safety. Autel Robotics' GNSS Base Station provides centimeter accuracy and supports all 4 major satellite systems.
Autel Voyager
Incredibly powerful yet simple to use, Autel Voyager is the one-stop solution for every mission. Designed specifically for the Dragonfish, the software provides advanced mission planning, intelligent tracking, flight history tracking, and other autonomous features.

• Mission Planning: Waypoint missions, polygon missions, and rectangular missions can be planned offsite prior to mission and started with a single click to begin autonomous flight. The pilot can regain control at any time during the mission for emergency maneuvers or custom flight path planning. • Tap to Fly: Select a target on the camera and the Dragonfish will automatically fly to the selected location and orbit the subject.
• Mission Management: Monitor past missions and assign flights.
• Quick Mission: Set points of interest on the flight map during any part of the mission and the Dragonfish automatically will deviate from its original path plan to pursue the pilot's needs.

9.7"1000NIT ultra-bright Ground Control Station
The high resolution (2048*1536), 9.7 inches, ultra-bright (1000 nits) TFT-LCD touchscreen ensures maximum visibility and practicality in all situations. Autel Ground Control Station is water, dust, and water resistant. Autel Robotics' new antenna design allows the video transmission to reach up to 18.6 miles (30km). The Autel Robotics ground station controller has a battery life of up to 6 hours and can be operated indefinitely with a remote power source.


Compact and Portable
The Dragonfish can be easily disassembled by a one man team and will fit in the back of typical car trunks. The entire system can be assembled without tools and is ready to fly in less than 5 minutes.

- The Dragonfish's fuselage is highly modular for easy packing and repair.
- The entire system self-checks in 5 seconds upon startup and is ready to fly immediately after.
- Tool-Free Quick Release Propellers


Endurance with Payload
The Dragonfish series includes three models: the Dragofish Lite, Dragonfish Standard, and Dragonfish Pro. With a flight time of 75 minutes, 120 minutes, and 180 minutes respectively while carrying a payload, each model can greatly improve work efficiency.

Autel Dragonfish Pro
Dimensions (L*W*H): 64.96*119.7*18.11 inch
Weight (Including Two Batteries, Without Gimbal): 31.96 lbs
Single Battery Weight: 7.93 lbs

Supported Payloads: Z2, T3, T3H, L20T, M1, L50T

Maximum Takeoff Weight: 37.48 lbs

Operating Frequency:
902-928 MHz;
2.4000-2.4835 GHz;
5.725-5.755 GHz

EIRP (Equivalent Radiated Power):
900MHz
FCC:< 30 dBm;
2.4 GHz
FCC:< 30 dBm
SRRC/CE/MIC:< 20 dBm;
5.8 GHz
SRRC/FCC:< 22 dBm
CE: < 14 dBm

Hovering Accuracy (P-mode with GPS):
Vertical:
±0.1 m(Vision System enabled)
±0.5 m(GPS enabled)
±0.1 m(RTK enabled)
Horizontal:
±0.3 m(Vision System enabled)
±1.5 m(GPS enabled)
±0.1 m(RTK enabled)

RTK Positioning Accuracy:
When RTK enabled and fixed:
Multi-rotor:
1 cm+1 ppm(Horizontal)
1.5 cm + 1 ppm(Vertical)
Fixed Wing:
3 cm+1 ppm(Horizontal)
3 cm + 1 ppm(Vertical)

Maximum Angular Velocity:
Pitch:180°/s
Yaw:60°/s

Maximum Pitch Angle: 20°
Maximum Roll Angle: 35°

Maximum Ascent Speed:
Vertical Flight Mode:8.94 mph
Fixed Wing Mode:11.18 mph

Maximum Descent Speed (Vertical):
Vertical Flight Mode:6.71 mph
Fixed Wing Mode:11.18 mph

Maximum Flight Speed: 67.10 mph

Flight Speed:
0 mph ~38 mph(Multi-rotor)
38 mph ~ 67.10 mph (Fixed Wing)

Service Ceiling Above Sea Level: 19,685 ft (6,000m)

Max Wind Resistance:
Fixed Wing Mode:33.5 mph
Vertical Flight Mode:26.8 mph

Maximum Flight Time: 180 Minutes
Maximum Payload: 5.51 lbs

Supported Gimbal Configurations: Fast Disassembly
Ingress Protection Rating: IP43
GNSS: GPS+GLONASS+BeiDou+Galileo

Operating Temperature: -20°C ~50°C (-4°F ~122°F)

Single Battery Energy: 822.36 Wh
Single Battery Charging Time: 120 Minutes

Recommended Storage Temperature: 22°C ~28°C (71.6°F ~ 82.4°F)
Charging Temperature Range: 15? ~40? (59°F ~ 104°F)
Operating Temperature: -20? ~40? (-4°F ~ 104°F)

Ground Control Station
Video Transmission:
Operating frequency:
902-928 MHz;
2.4-2.4835 GHz
Max Transmitting Distance (unobstructed, free of interference):
FCC:10 km
CE / MIC:5 km
SRRC:5 km

Data Transmission:
Operating frequency:
5.725 - 5.755 GHz

Wi-Fi
Protocol:
Wi-Fi Direct, Wi-Fi Display, 802.11a/g/n/ac
Wi-Fi with2 x 2 MIMO Wi-Fi
Operating frequency:
2.400 - 2.4835 GHz
5.150 - 5.250GHz
5.650 - 5.755GHz
5.725 - 5.850 GHz

Battery:
name: lithium ion polymer battery

Capacity: 8200mAh
Voltage:11.4 V
Type:Li-Po
Energy:93 Wh
Charging time:120 min

Run Time:
~3 hrs (Max brightness)
~4.5 hrs (Half brightness)
Storage Capacity:
ROM 256GB + scalable (TF)

Video Output Port: HDMI Port
Power Supply Current / Voltage (USB-A port): 5V / 500mA
Operating Temperature Range: -20? ~ 40?
Charging Temperature Range: 0? ~ 45?

Storage Temperature Range:
-20° ~ 60°(Within 1 month)
-20° ~ 45°(1-3 months:)
-20° ~ 30°(Within 1 year)

GNSS: GPS+GLONASS+Galileo

Dimensions:
319×233×74 mm(antennas folded)
319×398×74 mm(antennas unfolded)

GNSS receiver:
Satellite receiving frequency(Simultaneously receive:
GPS:L1,L2,L5
BeiDou:B1,B2,B3
GLONASS:F1,F2
Galileo:E1,E5A,E5B

Positioning accuracy:
Single Point
Horizontal: 1.5 m(RMS)
Vertical: 3.0 m(RMS)

RTK:
Horizontal: 1 cm+1 ppm(RMS)
Vertical: 1.5 cm+ 1 ppm(RMS)
1 ppm: For every 1 km increase in distance, the accuracy will be 1 mm less.
For example, the horizontal accuracy is 1.1 cm when the receiving end is 1 km away from the base station.

Positioning update rate:
1Hz,2 Hz,5 Hz,10 Hz ? 20Hz

Cold start: < 40s
Hot start: < 10s
Recapture: < 1s

Initialization reliability: > 99.9%
Differential data transmission format: RTCM 2.X/3.X

Wi-Fi:
Operating frequency:
2.400-2.4835 GHz;
5.125-5.25GHz;
5.650-5.755GHz;
5.725-5.850GHz

EIRP (Equivalent radiated power):
2.400-2.4835 GHz
FCC:< 26 dBm
SRRC/CE/MIC:< 20 dBm
5.125-5.25GHz
FCC/SRRC:< 26dBm
5.650-5.755GHz
MIC:< 20 dBm
5.725-5.850GHz
SRRC/FCC:< 26 dBm;CE: <14 dBm
SRRC/CE/MIC:< 20 dBm

Communication distance:
Mobile station and aircraft: 30km(FCC)
Mobile station and remote control: 200m(FCC)(Unobstructed and free of interference, when the mobile station is used as a base station and the distance from the mobile station antenna to the bottom of the tripod is 2 m; and when the difference in height between the remote controller and mobile< station is less than 10 m, and when the remote controller is 1.2 m from ground level)

Electrical characteristics:
Power consumption: 7.5 W
Power supply: 5 ~ 20V DC

Battery:
Type: lithium ion polymer battery Capacity: 4950 mAh Energy: 57.1 WH

Run time: > 7.5 h

Physical properties:
Size(Base station body + extension rod): 193 mm×177 mm×73 mm

Weight: 1275g

Dustproof and waterproof: IP65

Operating temperature: -20? ~ 50?

Other parameters:
Data Link
Video Transmission,Wi-Fi
Operating frequency:
2.4000-2.4835 GHz;902-928 MHz
EIRP (Equivalent radiated power)
902-928 MHz
FCC:< 30 dBm
2.400-2.4835 GHz
FCC:< 30 dBm
SRRC/CE/MIC:< 20 dBm

1 - Aircraft
1 - 9.7-inch Smart Controller
1 - Base Station
4 - Batteries
1 - Charger with AC Cable
2 - Clockwise A Propellers
2 - Counter-Clockwise B Propellers
2 - Base Station Antennas
2 - Base Station Feeder
1 - Airspeed Indicator Cover
1 - Base Station Tray
1 - Base Station Tripod
1 - Base Station Charger
1 - USB Type-C Cable
1 - Repair Toolkit
1 - Ground Station Charger
1 - Wing Set (Pair)
1 - Tail Component
1 - TF Card
1 - Ground Station Lanyard

Camera Options (Prices will vary)
1 - DG-Z2
1 - DG-T3
1 - DG-T3H
1 - DG-M1
1 - DG-L20T
1 - DG- L50T
